Cable Management Grommet for Equipment and Panel Assemblies
The Sugatsune matte black LS-50S-S-BL cable management grommet provides a controlled cable-routing point for equipment, panels, work surfaces, and other assemblies where connectors must pass through an opening. Its split configuration allows the grommet to separate so larger plugs and connectors can be routed through without requiring cable termination or disassembly.
Manufactured from zinc alloy, the LS-50S-S-BL combines a rigid metal body with integrated rubber components designed to lock the cover in place. The LS-50S-S-BL has a black finish and measures 2” (50mm) in diameter; it provides a large 1-¼” (32.2mm) opening to fit large cables. The grommet body has a mounting depth of 9/16” (15 mm) and requires a 1-9/16” (40 mm) cutout for installation.
Split Design With a Locking Lid
Themattee black equipment LS-50S-S-BL cable grommet incorporates a lid with a locking mechanism. Rubber stoppers positioned on the back side help prevent the lid from rotating or being unintentionally removed after installation.
For cable-routing applications, the split architecture is particularly useful when cables already terminate in plugs or connectors larger than the available pass-through opening. Simply wrap the grommet base around the cords and snap the lid into place. Engineers comparing this component with other configurations can review Sugatsune’s grommets and cable managers. Split grommets simplify routing of preassembled cables while maintaining an organized transition through panels or surfaces.
Sugatsune also provides CAD files to support component integration into engineered assemblies. For application-specific questions, contact Sugatsune America to discuss the installation with a technical representative.
FAQs
What size opening does the LS-50S-S-BL cable management grommet provide?
The overall opening of the LS-50S-S-BL is 1-¼” (32.2 mm) and requires a 1-9/16” (40 mm) cutout.
Why is the LS-50S-S-BL designed as a split cable grommet?
The split design allows the grommet to open around larger plugs and connectors. This can simplify installation when cables are already terminated and removing the connector is not practical.
What material is the LS-50S-S-BL cable grommet made from?
The LS-50S-S-BL is manufactured from zinc alloy and has a black finish. Its zinc die-cast construction provides a rigid cable-management component for integration into equipment, panels, and other engineered assemblies.
